Orion

Built in Minneosta

Orion

We are proud to announce our first solo canoe built in Winona, Minnesota using resin-infusion technology.

Starting Price: $3,699

Coming Soon

Create Your Orion
HANDRAFTED IN WINONA, CUSTOMIZED BY YOU.
The Orion is our first solo canoe model to be built in Winona, Minnesota. This flat water-touring canoe follows a shallow arch hull design with great secondary stability. Combining unparalleled efficiency with seaworthiness, this canoe is sure to gain a following among those who like to cover water and appreciate a canoe that inspires confidence regardless of conditions. Enjoy the increased pack space without sacrificing speed. The Orion also handles well on rivers and streams up to Class II giving the paddler a versatile option for most conditions.

This canoe is built using the latest in resin-infusion technology with the added protection of Maxguard premium gelcoat. These canoes are heirloom-quality products meant to be passed along to the next generation.

Purchase at a Dealer

Our dealers will carry a variety of Orion build-outs.
Visit them for current availability and purchase:

Stone Harbor Wilderness Supply - Grand Marais MN
Minnesota Canoes - Alexandria MN
Paddle Hoppers - Grand Rapids MN
Piragis Northwoods Company, Ely MN
Carl's Paddlin' - Lone Rock, WI
Chequamegon Adventure Co. - Minocoqua WI
Paddling Warehouse - Lake Bluff, IL

Custom Build Your Orion

On your own or with your local dealer

Follow the steps below and build your legacy today. We have 3 standard laminations to choose from along with several trim systems, add-ons, and custom gelcoat options.

Coming Soon

Orion Specs

Length: 16'0"
Max Beam: 28.5”
Gunwales: 26”
Waterline: 25.25”
Rocker: Bow 2.5” Stern 1”
Length/Width Ratio: 7.6
Optimal Load: 165-350
Sheerline: 16.5”/12”/14.5”
Weight (approx. with Aluminum Gunwales):
Legacy GOLD - 29 lbs
Legacy PRO - 32 lbs
Legacy GREY - 35 lbs

Build Options

Lamination: Legacy GOLD/GREY/PRO

Trim: Champagne or Black Alumi-Link , Standard-Link Wood

Color Options: Clear, Tinted, Full Pigment Gelcoats

Seat Mounts: Anodized Black Aluminum or Carbon Fiber

Extras: Sliding Bow Seat, Kneeling Thwart

built to last

Legacy Lamination

Legacy GOLD / PRO / GREY

Grey Duck Outdoor’s Legacy Lamination keeps up with the demands of the modern paddler in performance and integrity while striving to be as eco-conscious as possible.

By laying our cloth in the mold dry and placing our hulls under vacuum pressure before injecting resin into the cloth, we eliminate the opportunity for VOC emissions to escape into the atmosphere which creates a healthier working environment. We also increase the working time so each part of the canoe is placed precisely with unparalleled quality control.

Legacy GOLD

100% Aramid

Legacy GOLD provides the familiar yellow appearance and classic performance of aramid. Lightweight yet durable, this combination of materials is industry standard and performs exceptionally well in most paddling conditions.

Ideal Application: Extended Wilderness Trips by Attentive paddlers who want to treat themself to a lighter portage and paddling experience.

Weight: Approximate weight of the Vision17 with aluminum trim in the Legacy Gold lamination is 29 lbs.

*Photograph below is the Vision17 to show lamination.*

Legacy GREY

Basalt / Innegra / Aramid

Legacy GREY is our shop favorite. The soft grey interior finish of the basalt-innegra harmonized with our stunning trim packages and gelcoat palette creates a warmth and esthetic that is second to none. This canoe is built to last a lifetime while coming in at a final weight that is acceptable to most paddlers who spend more time paddling than they do carrying their canoe. If you want to invest in a canoe that you are certain will be enjoyed by future generations, then Legacy GREY was designed for you.

Ideal Application: General purpose paddling with the capacity for rugged wilderness tripping and inattentive children at the cabin.

Weight: Approximate weight of the Vision17 with aluminum trim in the Legacy GREY lamination is 35 lbs.

*Photograph below is the Vision17 to show lamination.*

Legacy PRO

Carbon / Innegra / Aramid

Legacy PRO is for the paddler that wants to discover the unknown and see what's just beyond the bend. Being our most versatile lamination, this is a "do-everything" recipe that provides the flexibility of Innegra, toughness of aramid, and efficiency of Carbon. If you want a light-weight option that can put up a fight with wild lakes and rivers then you will find a capable companion in Legacy PRO. Astounding beauty matched with the best features of our GREY and GOLD laminations, Legacy PRO brings you to the leading edge of composite canoes in the modern era. Standard options also include Translucent Red, Blue, and Green Gelcoat for a colorful cloth finish only available in Legacy PRO.

Ideal Application: Local lakes and rivers with an annual backcountry trip in mind, for the paddler that's ready for anything, anywhere, anytime.

Weight: Approximate weight of the Vision17 with aluminum trim in the Legacy PRO lamination is 35 lbs.

*Photograph below is the Vision17 to show lamination.*

innovative

Infusion Process

Cleaner air + Better Working Conditions: Removes VOC emissions as opposed to “wet-layup” methods.

Stronger hulls: Better resin to fiber ratio than "wet-layup" for optimal performance and durability.

Consistency: Increased Quality Control and Less Weight Variance.

Standard-Link

Our Standard-Link wood trim package follows a conventional trimming method that leaves little need for explanation. Ash gunwales and domestic wood components are neatly fastened with stainless steel hardware providing a subtle contrast and classic aesthetic. All manufactures use this method for its simplicity, repairability and ease of construction and so do we.

This trim package comes standard with ash parts and aluminum seat mounts.

Alumi-Link

Our Alumi-Link trim package is a lightweight and maintenance free trim that doesn’t break the bank. Champagne or Black anodized aluminum gunwales featuring a solid wood yoke provides a familiar aesthetic. Those looking for a lightweight and maintenance free trim option will find their match with our Alumi-Link trim system.

Gelcoat Options

Offering clear, tinted, and solid pigment Maxgaurd gelcoats along with bow-dip and two tone design options, the possibilities are endless! Stock gelcoat options are represented below and readily available. Our Custom Shop is here to help you truely express yourself through countless color combinations - we'll do what we can to bring your vision to life!
